دستگاه فرز فلز بر MECOF CS 88 G

This 3s MECOF CS 88 G Bed Type Milling Machine was manufactured in 1990. It features a working table length of 6,000 mm and a maximum permissible load of 8 tons per meter. The spindle motor power is 14.7 kW, with a speed range of 10 – 1,207 rpm. If you are looking to get high-quality milling capabilities, consider the MECOF CS 88 G machine we have for sale. Contact us for further details.
Location: IT
brand: MECOF
Control Brand: HEIDENHAIN
Control Model: T355A
Spindle Power: 14.7 kW
Taper Size: ISO 50
T-slots: 6 on table + 2 lateral
T-slot width: 22 mm
Distance between T-slots: 175 mm
Max permissible load: 8 tons per meter
X (longitudinal column): 4,300 mm (variants: 2,300 / 3,300 / 4,300 mm)
Y (ram cross): 1,000 mm
Z (vertical head): 1,700 mm (variants: 1,200 / 1,700 mm)
Constant torque range: 10–249 rpm
Spindle diameter (front bearing): 90 mm
Micrometric feed rates: up to 4,100 mm/min
Working feed rate: up to 4,200 mm/min
Rapid traverse: up to 4,600 mm/min
Spindle motor: Thyssen, DC
Axis feed motors: Servomac
Lubrication and hydraulic pumps: Sever / Willi Vogel
Cooling system: dedicated headstock oil cooling
Control unit: BE 412 B
Working table
Axis travels
Spindle
Feeds
Drives & motors
Heidenhain T355A
